1045 Cold Drawn Steel
Products Description
Cold rolled steel round bar/rod 1045 is normally used for industrial, machine, and tool applications. 1045 is a commonly used low carbon steel alloy with good strength, ductility, and ease of machining. AISI 1045 carbon steel stock is available in full size and custom cut lengths.
1045 Carbon Steel Q+T Heat Treatment Process
Quenching and tempering is a dual heat treatment process of quenching and high-temperature tempering, aimed at achieving good comprehensive mechanical properties of the workpiece.
Quenched and tempered steel can be divided into two categories: carbon quenched and tempered steel and alloy quenched and tempered steel. Whether it is carbon steel or alloy steel, its carbon content is strictly controlled. If the carbon content is too high, although the strength of the quenched and tempered workpiece is high, the toughness is not enough. If the carbon content is too low, the toughness will increase and the strength will be insufficient. To achieve good comprehensive performance of the quenched and tempered parts, the carbon content is generally controlled between 0.30% and 0.50%.
When quenching and tempering, it is required that the entire cross-section of the workpiece be quenched to obtain a microstructure mainly composed of fine needle shaped quenched martensite. By high-temperature tempering, a microstructure dominated by uniformly tempered martensite is obtained.
Equivalent Grade
| GB | 45# |
| ASTM | 1045 |
| JIS | S45C |
| DIN | CK45 |
Chemical Composition
| Grade | C | Si | Mn | Cr | P | S | Ni | Cu |
| AISI 1045 | 0.42-0.5 | 0.17-0.37 | 0.5-0.8 | ≤0.25 | ≤0.035 | ≤0.035 | ≤0.3 | ≤0.25 |
aisi 1045 Cold Drawn Steel Bar Processing:
EAF + LF + VD + CONCASTING BILLETS + HOT ROLLED + SHOT BLASTING +(ANNEALING) + COLD DRAWN + OILING + BUNDLING + BOTH ENDS CUTTING+ PACKING + MARKING
1045 carbon steel is a high-quality carbon structural steel with a carbon content of over 0.4%, which makes it have good cutting performance. After quenching and tempering, the hardness range of 1045 steel is HRC20 to HRC30, which ensures its superior mechanical properties. In addition, 1045 carbon steel hardness after quenching can reach around HRC50, and the highest can even reach HRC55, but such high hardness will reduce its mechanical properties. In order to achieve good comprehensive performance, 45 steel is usually subjected to quenching and tempering treatment, and surface quenching is carried out on this basis to improve surface hardness.
In addition, according to the GB/T699-1999 standard, the recommended heat treatment system for 45 steel includes 850 ℃ normalizing, 840 ℃ quenching, and 600 ℃ tempering to meet specific performance requirements, such as yield strength ≥ 355MPa, tensile strength ≥ 600MPa, etc. The hardness of quenched and tempered 1045 steel ranges from HRC20 to HRC30, which not only ensures the superiority of its mechanical properties but also maintains good processing performance.
Product Picture
Our factory
Steel Making
Ingot Production
Forged Bars
Machinary
Cold-drawn round steel is also called cold-drawn round steel. The surface of cold-drawn round steel is very smooth, its dimensional accuracy is high, and its mechanical properties are high. Because of its high dimensional accuracy, it can be used directly without processing.
1045 Cold Drawn Steel Application:
1): Can be used in many fields such as building, automobile, shipbuilding, petrochemical, machinery, medicine, food, electric power, energy, space, building and decoration, etc.
2): Can be made into mould template, mortise pin, column
3): This kind of steel have good mechanical property, is widely used in structural parts which may support stress alternation, especially made into some connecting rods, bolts, wheel gear...
4): This kind of steel is the most common blanks and materials of shaft parts. Its die welding material model is CMC-E45
Packing & Delivery
Packing & Delivery
-
The inner size of container is below:
-- 20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high)
-- 40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high)
-- 40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high)
FAQ
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. Or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra?
A:Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your MOQ?
A: Usually our MOQ is 5t. But if your quantity is small, the price may be a little higher. When there is a big quantity, the price will be quite lower.
Q:How to buy your ideal products?
A: You can provide us your drawing, and we will produce as your drawing. Or we can design as your requirements if you do not have a clear plan.
Q:How to pay?
A: TT and L/C are acceptable and TT will be more appreciated.30% deposit before producing, 70% balance before shipping.
Q:How to install after the goods destination?
A: We will provide installation instruction and video for you. Technicians will be sent to help you if it is necessary. However, the visa fee, air tickets, accommodation, wages will be provided by buyers.
Q:How to get an accurate quotation?
A:Product detail size & Length,product quantities,product material grade.
Q:What other items from this supplier?
A:Angle line structural steel, triangular solid bar, hexgonal bar, Channel,Square, rectangular, round hollow section pipe. Steel plate, checker plate, corrugated sheet, steel coil. Flat, round bar.
