Product Introduction

Products Description

1.2343 SKD6 Hot Forged Tool Steel H11 Forged Bar

H11 Die Steel Equivalent Grades:

Standard	AISI/SAE	W.Nr/DIN	JIS	GB
Grade	H11	1.2343	SKD6	4Cr5MoSiV

Typical Chemical Composition (%)

C	Si	Mn	Cr	Mo	V
0.33-0.42	0.80-1.20	0.20-0.50	4.80-5.50	1.10-1.60	0.30-0.60

High Mold Steel Material 1.2581 Tool and Die Steel Mould Steel H21 SKD5 Round Bar Steel

Heat Treatment of 1.2343/H11 steel plate

Annealing: 750 to 800ºC, slow cooling in furnace (10-20ºC/hr), down to 600ºC, cooling in air. Hardness after annealing: max. 230 HB.

Stress relieving: 600 to 650ºC, slow cooling in furnace. Hold in neutral atmosphere for 1 to 2hours.

Hardening: 1000 to 1040ºC, oil/air, hold 15 to 30 minutes. Hardness , 52 to 56 HRC in oil, 50 to 54 HRC in air.

Tempering: 560 to 580ºC. Slowly heating to tempering temperature right after hardening. Recommended to temper at least twice. The second tempering temperature shall be approx. 30ºC lower than the first tempering.

Tempering ºC	300	400	500	580
HRC	53	53	54	50

* Hardening temperature: 1020ºC, specimen size: dia50mm

Product Picture

1.2357 TOOL STEEL PLATE

Applications:

Heavy duty hot work tools and dies: mandrels, dies, and containers for metal tube and rod extrusion;
Hot extrusion equipment; tools and dies for the manufacture of hollow bodies, screws, rivets, nuts, and bolts.
Die casting equipment, forming dies, die inserts, hot shear blades, and plastic moulding dies.

A2/1.2363 Steel Round Bar/Flat Bar/Forged Steel Block/Wear Resistant Cold Work Tool Steel

Our factory

Steel Making

Ingot Production

Forged Bars

Machinary

Delivery

1.2347 TOOL STEEL PALTE

Packing & Delivery

Port:Any Chinese Port

The inner size of container is below:

-- 20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high)

-- 40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high)
-- 40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high)

Other Services

1 Cutting: Small pieces

2 CNC Machine: Produce as your drawing

3 Package: Bare/Nylon/Canvas/Wooden

4 Payment:T/T, L/C, O/A(request credit)

5 Transport:FOB/CFR/CIF/DDU/DDP (train/ship/Air)
