42crmo4 round bar
Produce Process:Hot rooled/Forged
Diameter:5mm-850mm
Products Description
42crmo4 steel is an industrial alloy material. 42crmo4 round bar is used to manufacture forgings that require higher strength and larger quenched and tempered sections than 35CrMo steel, such as large gears for locomotive traction, booster transmission gears, rear axles, heavily loaded connecting rods, and spring clips. 42CrMo4 steel can also be used for oil deep well drill pipe joints and fishing tools below 2000m.
1.7225 42crmo4 qt steel round bar for gear parts
Chemical composition(%):
| C | Si | Mn | Cr | P | S | Mo |
| 0.38-0.45 | 0.17-0.37 | 0.50-0.80 | 0.90-1.20 | ≤0.035 | ≤0.035 | 0.15-0.25 |
Equivalent grades:
| GB(China) | DIN(German) | AISI(USA) | JIS(Japan) |
| 42CrMo | 1.7225/42CrMo4 | SAE4140 | SCM440 |
Available size(mm):
| Flat Bar Size(mm) | 42crmo4 round bar size(mm) | |||
| Thickness | Width | Length | Diameter | Length |
| 10-280 | 200-2200 | 2000-10000 | 20-260 | 3000-6000 |
Recommend heat treatment:
| Quenching | Tempering | |||||
| Heating temperature/ºC | Cooling way | Hardness (HRC) | Tempering | Cooling way | Hardness | |
| temperature | (HRC) | |||||
| /ºC | ||||||
| 850-880 | Oil Cooling | 50-52 | 450-650 | Air cooling | ≥48 | |
Product Picture
Our factory
Steel Making
Ingot Production
Forged Bars
Machinary
42CrMo4 (1.7225 material) has high strength, toughness, good quenching performance and temper brittleness. After quenching and tempering heat treatment, 42crmo4 round bar can maintain good impact resistance and low-temperature impact toughness, thereby achieving high fatigue resistance limit. 42crmo4 qt material is suitable for manufacturing large and medium-sized plastic molds, transmission gears, rear axles, load-bearing connecting rods, spring snap springs, and deep drilling pipe joints in oil wells that require certain strength and toughness.
Feature:
1. 42crmo4 round bar has good strength, hardenability and toughness.
2. Under the high temperature,42crmo4 steel keeps high creep strength and long lasting strength .
Appliation:
42crmo4 qt material is used for Produceing load large, complex shape and valuable tool (e.g, scraper, gear, milling cutter, drilling, tapping, etc.)Cold forging die, forging tools;Strip cutting machine, heading forming die.
Packing & Delivery
Packing & Delivery
-
The inner size of container is below:
-- 20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high)
-- 40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high)
-- 40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high)
Our services:
1. Sizes material and others are all at your requirements and can be change.
2. Price varies on material, dimensions, finished craft and different payment.
3. We are direct manufacturer in machinery manufacturing with experience of many years.
4. Detailed production design can be made according to the information you offer.
5. Each 42crmo4 round bar will be passed the UT test.
6. We have an adequate inventory, so that we can effect a quickly delivery.
