Din1.7035 Steel Equivalent Standard steel GB in China is 40Cr, the German DIN standard material No. 1.17035/1.7045, German standard DIN grade 41Cr4/42Gr4, EN grade 18 British standard, the British standard BS steel 41Cr4, France AFNOR 42C4 France NF steel standard, standard grade of steel...

Send Inquiry

Product Introduction

Materials equivalent grade

ASTM	JIS	DIN	BS	NF
5140	SCr440	41Cr4(1.7035)	530A40	42C4

Din1.7035 chemical composition

Grade	C	Si	Mn	Cr	P(≤)	S(≤)
40Cr	0.37-0.44	0.17-0.37	0.5-0.8	0.8-1.0	0.035	0.035
SAE 5140	0.38-0.43	0.15-0.35	0.7-0.9	0.7-0.9	0.035	0.035
41Cr4	0.38-0.45	0.1-0.4	0.6-0.9	0.9-1.2	0.035	0.035

Good Price Alloy Carbon Steel Sheet 45cr/5145/SCR445/41cr4

Application of Din1.7035 Steel Plate
It is one of the most popular steel grades in the industry. After Q+T heat treatment, it usually is used to make parts. Such as the gears of machine tools, shaft, worm, spline shaft and etc. If it is through quenching and tempering; high-frequency quenching, it will be good choice for fittings with high hardness and wear resistance. For example, wheel gear, shaft, principal axis, crankshaft, arbor, inlet valve, bolt and etc.

Packing & Delivery

Port:Any Chinese Port

The inner size of container is below:

-- 20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high)

-- 40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high)
-- 40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high Good Price Alloy Carbon Steel Sheet 45cr/5145/SCR445/41cr4
